🕹️ Restrained Love Viewer (RLV) & RLVa Deep Dive

A comprehensive and highly technical guide for Second Life users, creators, and scripters who want to master RLV and RLVa—covering protocol behavior, implementation differences, scripting details, and best practices for inventory folder structure.

---

1. Introduction to RLV

1.1 What RLV Actually Is

• RLV is not a “feature” inside Second Life itself—it’s a viewer-side extension.
• It hooks into the viewer’s inventory management, attachment system, and chat handling.
• RLV allows scripted objects to control the avatar’s viewer through LSL commands relayed over special chat channels.

1.2 Historical Background

• Created by Marine Kelley around 2007 as a BDSM toolset.
• Originally limited to clothing restrictions, but expanded to full control over inventory, teleport, camera, and IMs.
• Inspired RLVa (alternative maintained by Catznip Viewer team).

1.3 Viewer Compatibility

• Officially supported in: Marine’s RLV viewer, Catznip (RLVa), Firestorm (with RLVa support).
• Unsupported in Linden Lab’s default viewer (no native RLV support).

---

2. RLV vs RLVa

2.1 Design Philosophy

• RLV: purist, strict, BDSM-oriented. Implements only what Marine considered valid.
• RLVa: pragmatic, debug-friendly, wider appeal. Implements additional features and “safer” defaults.

2.2 Debugging Tools & Logging

• RLVa includes Active Restrictions and Command Console panels.
• RLV does not expose this—more “black box.”

2.3 Differences in Command Handling

• Folder naming: RLV is stricter about hidden vs visible folders (., ~, + usage). RLVa is slightly more forgiving.
• Attachment add/remove: RLVa allows finer-grained handling of “add” vs “replace” operations.
• Auto-creation of #RLV: RLVa sometimes creates the folder automatically on login. RLV requires manual creation.
• Performance: RLVa caches folder lookups more efficiently when using large inventories.

2.4 User Experience Impact

• Users on RLV may find more things “just don’t work” without strict setup.
• Users on RLVa (e.g., Firestorm) get a smoother onboarding, at the cost of diverging slightly from Marine’s spec.

---

3. The RLV API & Protocol

3.1 Command Structure

• Commands are sent via chat channels (usually negative channel numbers).

• Format:

  [channel] /me command,param,param

• Example:

  @attach:foldername=force

3.2 Relay Objects & Channel Usage

• The Relay listens on channel -1812221819 by default.
• Devices (e.g., cuffs, cages) send commands → Relay interprets → Viewer enforces restrictions.
• Relay acts as a security layer—the viewer itself won’t accept raw @ commands without a relay.

3.3 Limitations & Quirks

• Commands are stateless unless reinforced—if you detach an item manually, some restrictions reset.
• Not all commands are implemented in all viewers (example: @redirchat works in RLVa, partially in RLV).
• Some restrictions persist after crash/logoff if not cleared properly.

---

4. Folder Structure in Depth

4.1 The #RLV Root Folder

• Must exist at inventory root.
• Name must be exact: #RLV. Case-sensitive.

4.2 Shared Folder Conventions

• Subfolders inside #RLV are directly exposed to RLV.
• Items can be force-worn, removed, or replaced by scripts.

4.3 Special Characters in Folder Names

• Symbols have semantic meaning:
• Use symbols to control behavior and improve navigation:
  • \ (backslash) → indicates a folder not to be worn directly but to access its subfolders.
  • + → indicates “add only,” preventing replacement of existing attachments.
  • +\ → a combination—both navigable and add-only.
  • . (period) → hides the folder from RLV except in specific contexts.
  • ~ → denotes items folders sent automatically via scripted devices.
• Avoid problematic characters like /, ,, | in folder names. Stick to safe symbols like ~!@#$%^&*()+-_={}[]\:;”‘.?.

4.4 The .outfits & .core Hierarchy

• .outfits = reserved system folder.
• .core = auto-added “base outfit” (always worn).
• Rules:
  • Only lowest-level folders in .outfits are valid outfits.
  • .core is merged into every outfit swap.
  • Duplicate items between .core and outfits may cause “replace vs add” conflicts.

4.5 “nostrip” Behavior & Locking Mechanisms

• nostrip → item will not be removed by @strip.
• Lock (@detach:folder=forbid) → item cannot be detached by wearer or RLV.

4.6 Folder Linking vs. Actual Folders

• Folders must be real.
• Items inside can be links (symlinks).
• But nested folder links break RLV.

4.7 Viewer Indexing & Performance Notes

• RLV constantly indexes the #RLV hierarchy.
• Deep nesting = slower operations.
• Optimal: 3-4 levels max for performance.

---

5. Advanced Inventory Management

5.1 Modular Outfit Building

• Build outfits like LEGO: body in .core, accessories in shared folders, themes in .outfits.

5.2 Mixed Mesh + Layer Workflows

• Keep system alphas in .core.
• Mesh clothing in .outfits.

5.3 Auto-Delivery from Devices

• Collars/cuffs often auto-create folders like ~CollarItems/.
• These appear under #RLV automatically.

5.4 Preventing Outfit Conflicts

• Don’t repeat unique items in .core and outfits.
• Use + folders for add-only items (jewelry, tattoos).

---

6. Scripting with RLV

6.1 LSL Relay Protocol Basics

• Relays must detect owner consent.
• Consent = dialog box popup (“This device wants to control you”).

6.2 Channel Handling

• Default relay channel: -1812221819.
• Devices often randomize channels for session security.

6.3 Example RLV Force-Wear Commands

// Force-wear "Bondage" outfit
llOwnerSay("@attach:Bondage=force");

// Strip all but nostrip items
llOwnerSay("@strip=force");

6.4 Security & Safety Considerations

• RLV is viewer-only. LL servers do not enforce it.
• Bad scripts can grief you if you don’t use a secure relay.
• Always verify relay settings before accepting control.

---

7. Known Viewer Differences

---

8. Troubleshooting & Pitfalls

• Multiple #RLV folders → undefined behavior.
• Misnamed .outfits → scripts won’t detect it.
• Inventory lag: large #RLV trees slow down login.
• “Phantom locks” → restrictions persisting after relog. Use @clear to reset.

---

9. References

• Marine Kelley’s RLV API
• RLVa vs RLV – Catznip Wiki
• Folder Setup Guide – Davro Sharkness
• OpenCollar Outfits Documentation
• Community Forum Threads on RLV setup and quirks

---

📂 Example ASCII Folder Layout (Extended)

Inventory/
└── #RLV/
    ├── \Accessories/
    │   ├── +Jewelry/
    │   └── +Piercings/
    ├── ~DeviceDrop/
    │   └── CollarScripts/
    ├── .outfits/
    │   ├── .core/
    │   │   ├── MeshBody (nostrip)
    │   │   ├── MeshHead (nostrip)
    │   │   ├── Eyes
    │   │   └── Collar
    │   ├── Schoolgirl/
    │   ├── LatexSuit/
    │   └── Chains/
    └── BondageGear/
        ├── +Cuffs/
        ├── +Blindfold/
        └── +Gag/
